For connection to a water tank. This means you can connect a low-pressure drinker, for example, using a hose. Connection 10 mm, at the thickest point (nut) 24 mm. Total length approx. 58 mm.
This connection plate is fitted as a replacement for the gearbox cover. The plate has 4 hydraulic connections on the top for P=pump, R=return, W=pressure transfer and Z=additional lift cylinder. This plate makes it possible to connect an externally mounted control unit. If no control valve with pressure transfer line is used, the W connection is closed. In order to guarantee the function of the tractor hydraulics with this installation, a shut-off-valve is fitted in the pressure line between connection P and the control valve. This must be closed when the three-point hydraulic system is used. This prevents pressure from escaping via the tank line of the additionally installed control valve.If a mobile control valve with pressure transfer line is used, connection W is connected to the pressure transfer line connection on the mobile control valve. This allows the tractor hydraulics and the mobile control valve to be used simultaneously. No shut-off-valve is required!Can be used in hydraulic systems of Ford tractor systems 3000, 4000, 5000.Max. Operating pressure: 250 barNominal flow rate 70 l/minTightening torque 78 Nm Connections M18x1.5 Dimensions (LxWxH): 160 x 130 x 20 mm
For connecting a drinking bowl to an IBC tank. including flexible armored hose 70 cm.Scope of delivery:1 x armored hose 70 cm (connection 2 x 3/4" female thread)1 x adapter for IBC container incl. seal (S60x6 to 3/4" male)1 x reduction straight 3/4" male to 1/2" female 1 x double nipple 1/2" male to 1/2 "AG1 x double nipple 3/4AG x 3/4AG
This set allows you to easily connect the diesel pump to the tank. This allows you to easily mount the pump on a wall or similar in the desired position. Hose length 2m. The connection set is delivered in individual parts so that you have the opportunity to adapt the hose length individually to your needs.
