Agricultural machinery

Lighting tester/tester for 7-pin plugs and sockets. Indicates possible cable defects on the vehicle or trailer in a flash, LED display (without battery).

This lighting tester makes it possible to quickly and easily check the 12V electrical system on trailers and towing vehicles. Thanks to the included adapters, suitable for 7 &~ 13 pin connectors. Battery 9V block (not included).

Trailer tester 12 VOLTLighting and cable tester for trailers / caravans and towing vehicles for 13-pin plugs and socketsDescription:Lighting and cable tester for trailers and towing vehicles. This handy test device ensures the quickest and easiest way to find cable defects on trailers and towing vehicles. The defective cable colors are displayed by the device using LEDs. All 13-pin sockets and plugs can be tested. Thanks to the internal battery supply, no external power source (running engine, car battery, etc.) is necessary. Ideal in commercial and private areas, for workshops, car and trailer rentals, accessories trade, etc.Product features:Lighting and cable tester for caravans/trailers and towing vehicles for 13-pin plugs and Sockets with German operating instructionsHousing made of impact-resistant PVCTest functions: brake, indicator and tail lights, rear fog lights, reversing lights, 12V continuous plus and 12V via ignitionNote: Unfortunately, for a few vehicles, the new generation, reliable measurement is not possible thanks to the CAN-BUS system.Offer contents:1x trailer tester 12 volt(For operation A 9 volt block battery is required (not included))

Complete with tail, brake, indicator and license plate lights, 7.5 m connection cable, 2 triangular reflectors, with plug and socket, with bulbs, fully wired, adjustable 1.3 - 1.7 m.

Complete with taillight, brake light, indicator light and license plate light as well as 7.5 m connection cable, adjustable: 1.1 m - 1.7 m, with 7-pin. Plug (without socket), 2 triangular reflectors, with bulbs.

Complete with tail, brake, indicator and license plate lights, 7.5 m connection cable, 2 triangular reflectors, with plug and socket, license plate, with bulbs, fully wired, adjustable: 1.3 - 1.7 m. Includes impact protection.

Adjustable 1.2 - 1.8 m, fully wired, 7 m connection cable with 7-pin plug, with tail light, brake light, indicator light, license plate light, 2 triangular reflectors.

Also suitable for Deutz/Steyr, 4 connections with screw terminals, with pre-heating function, installation dimension: 10 mm Connection terminals designation: 15 switched plus from ignition lock 17 starting glow system 19 glow system Pre-heating 50 starting current to starter (magnetic switch)

Transition from ball Italian system to Storz coupling. For coupling fire hoses or irrigation hoses to manure tanks with Storz couplings on the existing cup connection with hooks.

Transition from Bauer ball system to Storz coupling. For coupling fire hoses or irrigation hoses to manure tanks with Storz couplings on the existing cup connection.Galvanized version.3 inch = HK76, ball outside diameter D = 98 mm4 inch = HK108, ball outside diameter D = 145 mm5 inch = HK133, ball outside diameter D = 158 mm6 inch = HK159, ball outside diameter D = 180 mm8 inch = HK194, ball outside diameter D = 230 mm

Transition from the Perrot ball system to the Storz coupling. For coupling fire hoses or irrigation hoses to manure tanks with Storz couplings on the existing cup connection.

Transition from BecherItalian system to Storz clutch. For coupling fire hoses or irrigation hoses to manure tanks with Storz couplings on the existing ball connection.

Thread M 50 x 2, outer diameter 57 mm. 28 mm hexagonal.

Gearboxes with slip-on fasteners are an efficient, flexible and maintenance-friendly solution for driving hydraulic pumps. They enable optimum speed adjustment, resulting in improved performance and reliability of hydraulic systems in a wide range of applications. When selecting a suitable gearbox, the specific requirements of the application in terms of torque, speed and size should be taken into account.The connection for the PTO shaft is 1 3/8 x 6 teeth. The input speed can be up to 1000 rpm

Input speed 540 or 1000 rpm.

Transmission gear for hydraulic pumps of assembly 2 or 3 with quick-release fastener. The transmission has a through drive on a PTO shaft stub 1 3/8 x 6. The gear ratio is 1: 3.8. When using a hydraulic pump from assembly 2, a centering ring (Faie No. 112326) must be used. This ring reduces the centering seat of BG 3 from 50.8mm to the diameter of the centering seat of BG 2 of 36.5mm.

Input speed 540 or 1000 rpm.

Input speed 540 or 1000 rpm.

with 2 screw holes, 160x160mm

in white version, WxH:145x165mm ~

For tool-free attachment to a mounting triangle or the cultivator bracket. The device triangle is attached to the spreader with 4 screws.

​Mounting on the front of the radiator grille Total length: 450 mm

Length: 540 mmNote: Strip must be heated and adjusted to the hood!

3-way nozzle body for quick changing of nozzles of different sizes/spraying characteristics.Stop position between the spraying positions.ChemSaver membrane check valve for drip-free shut-off. Standard diaphragm opens at 0.7 bar. Membranes made of EPDM as standard, optionally made of Viton.Maximum operating pressure 10 bar.1/2"~ and 3/4"~ Versions with a hexagon socket in the top clamp for attachment to flat surfaces and rod profiles.Mounting via a 9.5 mm hole in the pipe.Maximum flow 6.1 l/min at 0.34 bar pressure drop, 8.6 l/ min at 0.69 bar pressure drop.
