Agricultural machinery

Version: for plugging

Pressure force 883 kg at 180 bar, connection G M16x1.5, nominal pressure 250bar

Pressure force 1272 kg at 180 bar, connection G M16x1.5, nominal pressure 250bar

Pressure force 2261 kg at 180 bar, connection G M18x1.5, nominal pressure 250bar

Pressure force 3534 kg at 180 bar, connection G M18x1.5, nominal pressure 250bar

Pressure force 5089 kg at 180 bar, connection G M18x1.5, nominal pressure 250bar

Single-acting hydraulic cylinder (plunger cylinder) without mounting parts on the piston rod and cylinder base. The piston rod has a diameter of 20 mm and is fitted with an extension lock at the lower end. Our cylinders are provided with a locating hole for dowel pins on the rod and base for easy attachment of fastening elements. A welding bevel is screwed onto the upper end of the piston rod.Pressure force 565 kg at 180 bar, connection G M14x1.5, nominal pressure 250bar

Single-acting hydraulic cylinder (plunger cylinder) with Ø16 mm ball joints. The piston rod has a diameter of 20 mm and is fitted with an extension lock at the lower end. The ball joint have a lubrication hole for lubricating the joint with a pointed nozzle.Pressure force 565 kg at 180 bar, connection M14x1.5, T = 35 mm, nominal pressure 250bar.

Single-acting hydraulic cylinder (plunger cylinder) with Ø16 mm ball joints. The piston rod has a diameter of 25 mm and is fitted with an extension lock at the lower end. The ball joint have a lubrication hole for lubricating the joint with a pointed nozzle.Pressure force 883 kg at 180 bar, connection M16x1.5, T = 35 mm, nominal pressure 250bar.

Single-acting hydraulic cylinder (plunger cylinder) with Ø20 mm ball joints. The piston rod has a diameter of 30 mm and is equipped with an extension lock at the lower end. The ball joints have a grease nipple for lubricating the joint.Pressure force 1272 kg at 180 bar, connection M16x1.5, T = 38 nominal pressure 250bar.

Single-acting hydraulic cylinder (plunger cylinder) with Ø20 mm ball joints. The piston rod has a diameter of 40 mm and is equipped with an extension lock at the lower end. The ball joints have a grease nipple for lubricating the joint.Pressure force 2260 kg at 180 bar, connection M18x1.5, T = 38 mm, nominal pressure 250bar.

Pointed blade for cutting attachment (counter blade) suitable for Aebi high and medium cutting beams. The rivet holes are countersunk on the underside of the blade.

Plastic pipe made of polyamide 12 according to DIN 16773 without fluid grease fillingMaximum operating pressure: 89 bar ~Bending radius (R): 40 mm ~Pipe diameter (A): 6 mm ~Wall thickness (S) : 1.5mm

12V, DC connection with 0.5 m cable, WxHxD: 44x66x28mm, incl. DC connector ~

12V, connection: grommet, WxHxD: 44x66x28mm

White, for front mounting, 60x60 mm, 30 mm hole spacing

12/24 V, 3-pole, mounting: 2 holes, hole spacing 45 mm, use e.g. John Deere,...

magnetic, incl. charger, IP65, Li-ion battery

​Magnetic, including two strong magnetic mounts for power bank and camera,with charger, 25000 mAh, 90 Wh, 12 V, 1 A Li-ion battery, IP65,Temperature range: -15°C to +60°C, Dimensions: 120 x 79 x 60 mm,Battery life: up to 32 hours

14 mm / M14 x 1.5 mm

Außendurchmesser: ø 178 mmAufsteckdurchmesser: ø 76 mm  Durch die Entfernung größerer Partikel verlängern diese Vorreiniger nicht nur die Lebensdauer der teuren Luftfilter, sondern minimieren auch die Ausfallzeiten der Maschinen und verlängern die Lebensdauer der Motoren.

Pre-glow coil - glow plug, installed in the cylinder headsuitable for Steyr engine WD 311, 411, 611Thread M22x1.5

Glow plug relay

Length: 36.5 mmWire thickness: 1.7 mm
