Agricultural machinery

Suitable for tractorsup to approx. 200 HP, piston K = 80mm, piston rod S = 40mm, pressure force 9047kg, pulling force 6785kg. CBM catch hook cat. 3 with ball cat. 3/2 25 mm, bolt 28 mm for joint head mount. Includes hydraulically unlockable check valve (locking block), 2 hydraulic hoses with connectors and dust caps, operating chain for catch hook and lift indicator. Indication of the installation length including the joint head.Please order the joint head that fits your top link bolt on the tractor/tractor with a bore of 25mm (Faie No. 102310), 28mm (Faie No. 102311) or 32mm (Faie No. 102312).The specified lengths always refer to bolt centre to bolt centre including the knuckle !

Suitable for tractor sup to approx. 140 HP, piston K = 70mm, piston rod S = 36mm, pressure force 6927kg, pulling force 5195kg. CBM catch hook cat. 3 with ball cat. 3/2 25 mm, bolt 28 mm for joint head mount. Including hydraulically unlockable check valve (locking block), 2 hydraulic hoses with plug and dust caps, actuation chain for catch hook and lift indicator.Indication of the installation length including joint head.Please order the joint head that fits your top link bolt on the tractor/tractor with bore 25mm (Faie No. 102310), 28mm (Faie No. 102311) or 32mm (Faie No. 102312).The specified lengths always refer to bolt centre to bolt centre including the knuckle !

Suitable for tractors up to approx. 250hp, piston K = 90mm, piston rod S = 40mm, pressure force 11451kg, pulling force 9150kg. Suitable for Fiat, Ford, New Holland and Steyr Profi. CBM catch hook cat. 3, with ball cat. 3/2 25mm. Including hydraulically unlockable check valve (locking block), 2 hydraulic hoses with plug, actuation chain for catch hook, top link bracket and lift indicator.Indication of the installation length including joint head.The specified lengths always refer to bolt centre to bolt centre including the knuckle !

Affordable hydraulic lower link adjustment for easy self-assembly. On slopes or tight curves, the entire three-point linkage can be moved laterally by up to 270 mm (depending on the tractor type) while driving. This means that, for example, when mowing on slopes, the incorrect cut, whether mowed twice or not mowed, can be compensated for by the mower drifting away. This investment is worth it with the first use.With M30x3.5mm internal thread in the piston rod for use on most tractors/trailers.Stroke 100 mm, installation length 345 mm, ball eye inner diameter 25.4 mm, outer cylinder diameter 105 mm, piston rod diameter 50 mm, hydraulic connections G1/2".Scope of delivery: hydraulic side brace as shown.Assembly: connect to a double-acting control valve with 2 hose lines.

The hydraulically folding bale fork with 2 tines is equipped with a three-point and EURO mounting. The thick-walled zinc support tube with welded-in cone sleeves can be folded upwards hydraulically. This means that no fork protection is required for road transport. The high-quality square spring steel tines with a length of 1100 mm have an M22x1.5 mm thread and can bear loads of up to 1000 kg. The distance between the conical sleeves for the tines in the support tube is 660 mm.The spring steel tines, the hydraulic lines and the BG3 coupling plugs are included in the scope of delivery.

Aussendurchmesser: 85 mmGesamtlänge: 80 mm

Innendurchmesser: 85 mmAussendurchmesser: 97 mmLänge: 241 mm

Version: for screwing 12 V / 24 V, nut M26 x 1 26.5 mm with recess 33.5 mm x 7.5 mm (twist-proof) for wall thickness up to 2 mm. Key can be removed in any position 250 W (terminal 15), 100 W (terminal 56a, 56b), 150 W (terminal 58). Switch positions: 0 = Off 01 = Ignition on 1 = Marker light 2 = Low beam 3 = High beam. with screw terminals 15, 30, 30, 56a, 56b, 58, 58~ Housing 48 mm

6 ports

with 7 connections, for insertion hole 19mm

Number of contacts: 7

Einbauöffnung: ø 27mm

4 switching positions with preheating, suitable for Lamborghini, Same, 40 mm, mounting hole 22 mm

Passend zu Massey Ferguson 135, 240

Passend zu Massey Ferguson MF35

Zündschloss passend zu John DeereAusführung: 5 Anschlüsse

Gear ratio 1:2, same direction of rotation, weight: 26 kgInputx: 540 rpm, 51.5 kW, 928 Nm, connection 1 3/8"x6 stubsOutput y: 1080 rpm, 460 Nm, connection 1 3/8"x6 inner profileIn general, torque peaks up to 2 times the nominal torque do not cause any damage to the individual gear components. However, complete integrity can only be guaranteed by a suitable safety device.

Flat plug connection, silver-plated, BA9s socket for 2W light bulb. (without bulb)

For Steyr Plus. Installation dimensions: 210x20 mm (without lamp holder)

Multi-chamber light specifically for the Steyr Plus series. With reflector 207x120 mm, 2 screws M5x20 mm, distance 45 mm. For front installation.

Metal base plate with PVC ring, 2 holes for fastening with M5 screws, 45 mm hole spacing, 78 mm, suitable for e.g. Case IH, Claas, Deutz, Holder, Johne Deere, MF, ...

For mounting at the front, base plate made of impact-resistant plastic, cover glass with snap fastening, 2 holes M5, 70 mm hole spacing, can be used right/left, LxWxH: 170x75x64 mm, suitable for e.g. Case IH, John Deere, ...

Front attachment, 2 holes M4, hole spacing 104mm,LxWxH: 125x63x49mm,suitable for e.g. Class, Deutz, John Deere right/left
