System bauer
Clutch cup for BAUER system
with sealing ring, black3 inch = HK 76, cup width B = 98 mm3 1/2 inch = HK 89, cup width B = 120 mm4 inch = HK 108, cup width B = 145 mm5 inch = HK 133, cup width B = 160 mm6 inch = HK 159, cup width B = 180 mm8 inch = HK 194, cup width B = 230 mm
Coupling ball for BAUER system
black, without lever lock ring3 inch = HK76, ball outside diameter D = 98 mm4 inch = HK108, ball outside diameter D = 145 mm5 inch = HK133, ball outside diameter D = 158 mm6 inch = HK159, ball outside diameter D = 180 mm8 inch = HK194, ball outside diameter D = 230 mm
Double flange elbow 90� 6 radius 195mm
Pipe elbow 90 in size 6" with two flange connections. The square 4-hole flange has the dimensions 180x180mm. The hole spacing of the holes is 150x150mm and the holes have a diameter of 13mm. The double flange elbow has a radius of 195mm and a height of 285mm.
End cap with ball, galvanized
3 inch = HK76, ball outside diameter D = 98 mm4 inch = HK108, ball outside diameter D = 145 mm5 inch = HK133, ball outside diameter D = 158 mm6 inch = HK159, ball outside diameter D = 180 mm8 inch = HK194, ball outside diameter D = 230 mm
End cap with cup and sealing ring, galvanized
Flange connection with ball, galvanized
Flange hole pattern 150x150 mm, for size 8" 180x180 mm3 inch = HK76, ball outside diameter D = 98 mm4 inch = HK108, ball outside diameter D = 145 mm5 inch = HK133, ball outside diameter D = 158 mm6 inch = HK159, ball outside diameter D = 180 mm8 inch = HK194, ball outside diameter D = 230 mm
Flange connection with cup and sealing ring, galvanized
Flange hole pattern 150x150 mm, for size 8" 180x180 mm3 inch = HK 76, cup width B = 98 mm3 1/2 inch = HK 89, cup width B = 120 mm4 inch = HK 108, cup width B = 145 mm5 inch = HK 133, cup width B = 160 mm6 inch = HK 159, cup width B = 180 mm8 inch = HK 194, cup width B = 230 mm
Hose connection with ball, galvanized
Hose coupling with ball and locking ring suitable for the Bauer coupling system. The couplings are available in the dimensions listed with different diameters of the connecting pieces for the hose.Galvanized version.3 inch = HK76, ball outside diameter D = 98 mm4 inch = HK108, ball outside diameter D = 145 mm5 inch = HK133, ball outside diameter D = 158 mm6 inch = HK159, ball outside diameter D = 180 mm8 inch = HK194, ball outside diameter D = 230 mm
Hose connection with cup and sealing ring, galvanized
Hose coupling with cup and sealing ring suitable for the Bauer coupling system. The couplings are available in the dimensions listed with different diameters of the connecting pieces for the hose.Galvanized version.3 inch = HK 76, cup width B = 98 mm3 1/2 inch = HK 89, cup width B = 120 mm4 inch = HK 108, cup width B = 145 mm5 inch = HK 133, cup width B = 160 mm6 inch = HK 159, cup width B = 180 mm8 inch = HK 194, cup width B = 230 mm
Lever lock ring, black
Lever locking ring, galvanized, suitable for the Bauer system
Pipe bend 90� with sealing ring, galvanized
Quick coupler suitable for the BAUER system
Hand lever can be positioned on the left or right, handle part can be adjusted four times in 90 increments, clamping path, clamping strength and closing force are infinitely adjustable, secured against self-loosening, ventilation via 1/2" ball valve.
Reduction from ball to cup
Reduction from cup to ball
Sealing ring system Bauer
B = inner x thickness.
Side distributor nozzle, spreading width 11 m
With the special side distribution nozzle, the manure fan covers a width of 11 m and hits the ground at a distance of 2 m - 13 m from the center of the barrel. Therefore, there is no path pollution.
Side nozzle with ball, galvanized
3 inch = HK76, ball outside diameter D = 98 mm4 inch = HK108, ball outside diameter D = 145 mm5 inch = HK133, ball outside diameter D = 158 mm6 inch = HK159, ball outside diameter D = 180 mm8 inch = HK194, ball outside diameter D = 230 mm
Spray nozzle with ball, galvanized
3 inch = HK76, ball outside diameter D = 98 mm4 inch = HK108, ball outside diameter D = 145 mm5 inch = HK133, ball outside diameter D = 158 mm6 inch = HK159, ball outside diameter D = 180 mm8 inch = HK194, ball outside diameter D = 230 mm
Threaded socket with ball, galvanized, for Bauer system
The threaded connector with ball (male part - VT) for the Bauer system is supplied complete with locking ring. The surface is galvanised.3 inch = HK76, ball outside diameter D = 98 mm4 inch = HK108, ball outside diameter D = 145 mm5 inch = HK133, ball outside diameter D = 158 mm6 inch = HK159, ball outside diameter D = 180 mm8 inch = HK194, ball outside diameter D = 230 mm
Threaded socket with cup and sealing ring, galvanized, for System Bauer
The threaded connector with cup (nut part - MT) for the Bauer system is supplied complete with sealing ring. The surface is galvanised.3 inch = HK 76, cup width B = 98 mm3 1/2 inch = HK 89, cup width B = 120 mm4 inch = HK 108, cup width B = 145 mm5 inch = HK 133, cup width B = 160 mm6 inch = HK 159, cup width B = 180 mm8 inch = HK 194, cup width B = 230 mm
Transition ball system Bauer to Storz coupling
Transition from Bauer ball system to Storz coupling. For coupling fire hoses or irrigation hoses to manure tanks with Storz couplings on the existing cup connection.Galvanized version.3 inch = HK76, ball outside diameter D = 98 mm4 inch = HK108, ball outside diameter D = 145 mm5 inch = HK133, ball outside diameter D = 158 mm6 inch = HK159, ball outside diameter D = 180 mm8 inch = HK194, ball outside diameter D = 230 mm
Universal distributor Original Bauer
No nozzle is included in delivery.3 inch = HK76, ball outside diameter D = 98 mm4 inch = HK108, ball outside diameter D = 145 mm5 inch = HK133, ball outside diameter D = 158 mm6 inch = HK159, ball outside diameter D = 180 mm8 inch = HK194, ball outside diameter D = 230 mm
