Slurry compressor, slide valve

Surface untreated.

Battioni &~ Pagani. ~

simple, 1/4? connection.

double, connection 1/4?.

Flange plate with hole for connecting fittings and pipes. The surface of the flange plate is untreated and is therefore suitable for welding on various connecting parts. ~

8"~ x 200 mm, hole pattern 180x180 mm, tube inner 206 mm, tube outer 220 mm

4"~, 5"~, 6"~ x 150 mm, hole pattern 150x150 mm, tube inner 157 mm, tube outer 169 mm

The flange socket with a 17 inclination is often used as an adapter between a quick coupler and the gate valve. The 17 inclination makes the quick coupler easier to use and the hose line easier to attach.

Galvanized, fastened with the help of an additional wide band clamp

To fix the slider in the open position.For brass manure sliders and knife sliders.

Brass lever slide with internal thread.

Fully galvanized, hydraulic connection 12L, thread M18x1.5. Single-acting, reset by maintenance-free gas spring, screw-in thread on the manure scraper M30x2.

Flange hole pattern 150x150 mm, bore 13 mm

Due to the enlarged housing to 102 cm and the resulting larger gaps in the flow area, these manure scrapers are no longer as susceptible to clogging due to solid particles (straw, hay, leftover feed, etc.) in the manure. See also heavy-duty manure scraper with threaded connection. Max. pressure 4 bar. Flange hole pattern 150 x 150 mm

Flange hole pattern 150x150 mm, bore 13 mm

Due to the enlarged housing to 102 cm and the resulting larger gaps in the flow area, these manure scrapers are no longer as susceptible to clogging due to solid particles (straw, hay, leftover feed, etc.) in the manure.

The overflow valve has a connection for a pressure relief valve with a 2? internal thread and for a vacuum gauge with a 3/8? internal thread. The large float ball is a lightweight PVC ball. The smaller PVC ball attached to the sealing lip is heavier in order to achieve optimal sealing.

with bayonet lock

with internal thread, inner 110 mm

with ring closure

TV tested, setting range: 0.3 to 1.5 bar

Can be used for 4"~, 5"~ and 6"~ Brass gate valves and knife gate valves.

With 2 fabric inserts for higher pressures, thickness 5 mm, 180x180x5 mm, hole spacing 150x150 mm.
