Agricultural machinery

For converting the mechanical locking to a hydraulic locking of the implements with a double-acting cylinder. Including 1.5 m hose, connection M18x1.5/12L union nut.In conjunction with guide no. 103099 (see accessories) you can attach this conversion kit to any quick-change frame. The installation length L(min) is 714mm. With the stroke of 150mm, the maximum length L(max) is 864mm. The locking bolt has a diameter of 20mm.We would like to point out that the hydraulic control circuit for the locking cylinder has a flow rate of 10-15L/min. and the maximum pressure should be limited to 160bar.

Thinner for painting synthetic resin varnishes

Suitable for bird &~ Noot plow body M350, MPK400, MPK430, UL430, ULST430, UN300, UN350, UN400, UN430, UST400, WL430, WL430 PLUS, WS350, WS400, WX400 PLUS, WY350, WY400, WY400 PLUS

Suitable for plow bodies B, C, BS40, BS42, US35, US40

Can be used right and left

Can be used right and left

M10x65.

Supplied with corrugated sealing ring, gasket and adapter

Complete with connection cable set, 0-4000 rpm, Ø 80 mm, with adapter ring for 100 mm diameter.The signal for RPM measurement is supplied via terminal W from the alternator.10-32V analog LCD tachometer with stepper motor technology, 4000 rpm, white LED illumination, and an orange hour meter.Drilling template with 100.5 mm diameter, IP65 rated on the front.Operating temperature -20°C to +90°C.Programmable via two buttons on the back of the instrument.4-pin Molex Minifit Jr. connector.90 cm connection cable included.EMC: ISO 7637-2 ISO 2575Technical specifications:Rated voltage: 10-32 VDisplay type: analog - digitalWidth: 10 cmOperating temperature: -20° / +85° CScale: 0-4000 RPMBore diameter: 100 mm

(Without testing) Thread 19 mm, A: 19 mm, B: 70 mm, ball 50 mm, recommended trailer load 500 kg!

Tested according to DIN 74058 and ISO. Complete with self-locking nut. Permissible trailer load 3500 kg, tongue load 100 kg. Thread M22x1.5, A: 26 mm, B: 65 mm.

82 mm, 2 screws M5, screw spacing 45 mm, base plate metal

Two-chamber light, base plate made of plastic, screw fastening, 2 holes 5mm, hole spacing 45mm, LxWxH: 95x85x55mm

(without lamps), rounded shape, WxHxD: 107x100x52 mm.

Plastic housing 140 mm, 2 holes for M6 screws, 45 mm hole spacing.

Three-chamber light HELLA, LxWxH: 95x90x54 mm, 2 holes M5, 45 mm hole spacing, suitable for e.g. Case IH, John Deere, Deutz, Fendt, ...

Suitable for Fendt series: Farmer, Farmer 100 / 300, Favorit 500, ~ ~GTADimensions: 158x64 Hole spacing M 5: 45 mm &~ 98 mmwith license plate lighting thanks to replaceable lens insert
